Scale SC019

0.2 Meter XLR Male to TRS Cable in High-Quality Metal
SKU: 117172
GTIN: 7090051113593
Availability: In stock
€8,99
€8,99
Please hurry! Only 150 left in stock
Subtotal: €8,99
10 customers are viewing this product

Scale SC019

Scale SC019

€8,99

Scale SC019

€8,99

Our Touring Grade cables are carefully crafted to withstand the toughest conditions. Designed to deliver top-quality performance at an exceptional value, we understand that your cables need to sound great and be reliable, day after night, without breaking the bank! That’s why we use a thick, yet flexible 6.5mm jacket that resists twisting and tangling. Our proprietary conductor technology and robust shielding ensure your sound is crystal-clear, free from noise or interference, every time. Each cable is hand-tested before shipping from the factory, and we back our quality with a lifetime warranty, so you can be confident that your cables will remain an integral part of your gear for many years to come.

4-Core Twinning Process
Our 4-core twinning process (2 conductors + 2 filled PVC tubes) provides a more stable physical structure and produces less noise when the cable is in motion compared to two-core cables.

Features:

  • High-performance microphone cable
  • 6.5mm high-quality rubber cable
  • Hand-soldered custom male XLR connector
  • Hand-soldered custom 1/4-inch TRS connector with 24K gold-plated contacts
  • Conductor: 28 x 0.10 x 2mm (OFC)
  • PVC jacket: 6.5mm
  • Spiral protection: 84 x 0.10 (OFC)
  • Cable:
    • Type: MC04
    • Color: black
    • Conductor area: 0.22 mm2 / AWG 24
    • Composition of conductor: 28 x 0.10 mm, bare annealed copper, OFC
    • Conductor insulation: LD-PE Ø 1.35 mm
    • Composition of cores: 4-core twining process, 60 MM one turn, left hand
    • Composition of conductor: 28 x 0,10 mm
    • Filler: Cotton Strand
    • Shield: 84 *0.10 mm, bare annealed copper, OFC
    • Jacket material: Phthalate free PVC with restricted substance
    • Working temperature: Mobile: -5°C to +70°C, Fixed: -20° to +70°C
  • Connectors:
    • Model name: SC013 / SC002
    • Product type: XLR male / TRS male
    • Number of poles: 3
    • Contact surface: black
    • Connection type: solder contact
    • Colour: gold
    • Housing: Cast zinc
    • Clamping sleeve: Polyacetal (POM)
    • Temperature range: -30 °C to +80 °C
